Eibach 2022+ Nissan Frontier Pro-Truck Stage 2R Coilover Kit # E86-63-045-02-22

This Eibach Pro-Truck Stage 2R system # E86-63-045-02-22 is designed for use on 2022, 2023, 2024 and 2025 model year Nissan Frontier trucks. The PRO-TRUCK-LIFT STAGE 2R features the ability to fine tune your lift height with threaded height adjustment and includes upgraded PRO-TRUCK Reservoir equipped rear shocks. The PRO-TRUCK-COILOVER 2.0's utilize extended travel monotube coilovers and variable force valving which delivers control during on-road transit and compliance for maximum traction on the trails. Designed for use with Eibach's interchangeable championship winning ERO Off-Road Race Springs, this system allows for various combinations to fine tune ride height and load capacity from fully loaded crawlers to factory weight vehicles. Due to height and weight differences across the Frontier model lineup we are unable to tell you exactly how much lift these coilovers will provide out of the box. But don't worry... they are easily adjusted using the provided spanner wrench! The rear shocks do not provide any lift but they are compatible with rear lift heights from stock up to 1.50" inches over the factory height.

Eibach # E86-82-45-02-22 Features:

Utilizes ERO Championship proven Off-Road racing springs
Front coilovers allow adjustment of 0.5" up to 1.9" (varies by sub-model)
Pre-assembled for direct bolt-on installation
Reservoir equipped Rear shocks can accommodate +1.5" of lift
Developed specifically to provide a balanced ride quality on and off-road
Made by Eibach in the USA
Zinc-coated shock tubes and anodized brackets to protect against corrosion
5/8" hardened, nitrocarburized rods for un-matched materials quality
Billet aluminum spring seats for strength
Sturdy 46mm tubing
Maxima (R) shock oil - because we only select the best

Important Fitment Information:

This Eibach system will provide more lift out of the box on 2wd models than 4x4 and Pro4X models. Eibach sets the coilover to provide a near level stance for 4wd trucks. 2wd models will require coilover adjustment to be level with OE rear height.

Eibach E86-63-045-01-22 includes a pair of Eibach E86-63-045-01-20 front coilovers that arrive fully assembled and a pair of reservoir equipped rear shocks # E60-63-045-02-01. To make adjustment easier Eibach also includes 1 x 6mm adjustment spanner wrench and all required mounting hardware! Please note - When installing the rear shocks you will reuse your factory hardware (nuts and bolts).

For more information on this or any other Eibach product please click on the Ask A Question link located at the very top of this page.
