Fabtech 2014 - 2017 Nissan Titan 6" Lift - Performance System # K6008

Fabtech Motorsports 6" Suspension Lift # K6008 is designed to be installed on 2014, 2015, 2016 and 2017 model year Nissan Titan (non-XD) trucks. This lift fits 2wd and 4x4 models. Fabtech is able to achieve 6" of front suspension and still retain the factory front shock and spring assembly by using a steel coilover spacer in conjunction with a drop subframe and taller steering knuckles. This means the Fabtech system helps improve upon the stock ride characteristics of the vehicle. How is this possible? The Fabtech Performance system includes a spacer for the front and Performance Series rear shock absorbers. Another benefit of the Fabtech design, the rack and pinion steering system does not need to be relocated for installation. This Fabtech 6" lift system includes a 1/4" thick differential skid plate, impact struts, and more. The rear is lifted using a 3" block and U-bolt kit that provides 3" of rear suspension lift and levels the 2014-2017 model year Titan front to rear.

Fabtech K6001 Kit Contents:
FTS25021BK - Front Component Box 1 of 2
FTS25022BK - Front Component Box 2 of 2
FTS7333 - Performance Series Rear Shocks

Tire & Wheel Fitment:
Fabtech recommends that wheels not be wider than 9.00" inches or have more than 5.00" inches of back space. Use of a wheel that is too wide or with too little back space may cause tire clearance issues. In general a narrower wheel with 5.00" of back space will work best with this lift. With the correct size wheels a 35" tires fits with room to spare. If you want to run 37" tires the Fabtech 6" lift can be modified to achieve up to 8" inches of lift. Additional (expensive) parts are required to do this that are NOT included in the K6008 kit boxes.

For more information on this or any other item, please click on the "ask a question" link located at the very top of this page.
