This ReadyLift # 69-30320 SST suspension lift kit provides a 3" front lift with forged torsion keys coupled with re-engineered heavy-duty fabricated 4130 chromoly steel upper control arms including all-new heavy-duty high angle ball joints and maintenance-free TCT non-bonded pivot bushings. In the rear, ReadyLIFT provides lift blocks for a lifted, level stance that retains factory load capacity, while all four corners of the truck receive Falcon 1.1 Monotube shocks to deliver the best-lifted ride quality available.

ReadyLift # 69-30320 Features:

· 3" Front/ 1" Rear SST Lift Kit
· Fits 2020-2024 MY GM HD 2500/3500
· SST lift-specific Forged Torsion Keys
· Front and rear Falcon 1.1 Monotube series shocks
· Xtreme-Duty fabricated 4130 chromoly steel Upper Control Arms
· Front inner fender bracket to increase larger tire clearance
· Allows for no-trim 20x9 0 offset on a 35x12.50 tire.
· *Max with trimming: 20x10 -18 offset - 35x12.50. Some fender well trim variances may be experienced between Silverado and Sierra models.

Falcon MonoTube Shock Information

The included Falcon Shocks provide the ultimate blend of Performance, Quality, and Bang for the Buck. Falcon 1.1 Monotube Shocks deliver increased stability improved ride quality and comfort for a daily-driven vehicle in an economical, compact performance package. These shocks have been optimized for this application and provide increased stability over stock for vehicles driven on and off road. The shocks feature a 2-1/8" shock body, 6061-T6 aluminum alloy billet piston and 1/2" induction hardened chrome plated shafts that resist rock damage corrosion and shaft buckling.

Important Installation Notes - Please Read!

When setting the torsion key adjustment bolt do not exceed 27” from the wheel center to the fender edge. Exceeding this will over lift the vehicle a creates a suspension top out condition, meaning the suspension has little to no down travel. The result is poor ride quality and premature wear of components.

For more information on this or any other ReadyLIFT product please click on the Ask A Question link located at the very top of this page.
